Pi Zero 2W and 16MP IMX519 *** no cameras available ***

I have tried three separate 16MP cameras on two different Pi Zero 2W boards.
I’ve tried the two recommended legacy OS installs from the quick start guide, as well as the current versions of Bullseye and Buster (updated and not updated)… no joy.

No matter wth the combination, libcamera returns *** no cameras available ***. I’ve tried ‘i2cdetect -y 0’, and don’t see any device.

There seems to be an issue with Bullseye and libcamera, Pi Zero W2 and Bullseye: *** no cameras available *** - Page 2 - Raspberry Pi Forums
However, I haven’t found a reported issue with Buster, aside from a comment from TomsHardware stating they never got the 2W to work during their review. Arducam High-Resolution Auto-focus Camera for Raspberry Pi Review (Updated) | Tom's Hardware

I’d be happy to hear from anyone with success / suggestions for the 16 MP camera.

Yes, the first version of Bullseye system had issues with Pi Zero 2W support, but on the latest Bullseye version (01/28) this issue has been resolved. You can try the latest Bullseye SD Card Image.

Well that’s good news.

However, I made a fresh install of 32 bit Bullseye 11.2. Followed the instructions to the letter, and still no camera, and nothing on I2C… is there some other way to check whether the camera is present? FYI: I’m using the cameras and flex cable from the quad camera kit.

In case, I have attached the Arducam install log

[email protected]:~ $ wget -O install_pivariety_pkgs.sh https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/install_script/install_pivariety_pkgs.sh
chmod +x install_pivariety_pkgs.sh
--2022-02-28 17:35:58--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/install_script/install_pivariety_pkgs.sh
Resolving github.com (github.com)... 52.64.108.95
Connecting to github.com (github.com)|52.64.108.95|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/e87fb062-32dc-4db3-b953-aeeb6e093e99?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043559Z&X-Amz-Expires=300&X-Amz-Signature=6771a5bdd9cc2c67bdd5e7076172d01c0928972d6f44a6531cf69cda2f23a765&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dinstall_pivariety_pkgs.sh&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:35:59--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/e87fb062-32dc-4db3-b953-aeeb6e093e99?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043559Z&X-Amz-Expires=300&X-Amz-Signature=6771a5bdd9cc2c67bdd5e7076172d01c0928972d6f44a6531cf69cda2f23a765&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dinstall_pivariety_pkgs.sh&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.111.133, 185.199.108.133, 185.199.109.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.111.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 4508 (4.4K) [application/octet-stream]
Saving to: ‘install_pivariety_pkgs.sh’

install_pivariety_p 100%[===================>]   4.40K  --.-KB/s    in 0.002s

2022-02-28 17:36:00 (2.53 MB/s) - ‘install_pivariety_pkgs.sh’ saved [4508/4508]

[email protected]:~ $ ./install_pivariety_pkgs.sh -p libcamera_dev
=================================================
Hardware Revision: 902120
Kernel Version: 5.10.92-v7+
OS Codename: bullseye
ARCH: armv7l
=================================================

--2022-02-28 17:36:16--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/install_script/packages.txt
Resolving github.com (github.com)... 52.64.108.95
Connecting to github.com (github.com)|52.64.108.95|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/f24c104d-d824-424c-b162-f9187466c267?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043616Z&X-Amz-Expires=300&X-Amz-Signature=eccab43dbbdd8ec9d304529f8b00f9d97196d37062d4df63f3583bfd736408db&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dpackages.txt&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:36:17--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/f24c104d-d824-424c-b162-f9187466c267?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043616Z&X-Amz-Expires=300&X-Amz-Signature=eccab43dbbdd8ec9d304529f8b00f9d97196d37062d4df63f3583bfd736408db&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dpackages.txt&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.111.133, 185.199.108.133, 185.199.109.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.111.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 1106 (1.1K) [application/octet-stream]
Saving to: ‘packages.txt’

packages.txt        100%[===================>]   1.08K  --.-KB/s    in 0.001s

2022-02-28 17:36:18 (1.35 MB/s) - ‘packages.txt’ saved [1106/1106]

--2022-02-28 17:36:18--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/install_script/libcamera_dev_links.txt
Resolving github.com (github.com)... 52.64.108.95
Connecting to github.com (github.com)|52.64.108.95|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/a10aada0-a139-4ac9-8e2e-2ba3e7b9c13b?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043619Z&X-Amz-Expires=300&X-Amz-Signature=15c041341623e2d937ea3d8b9dbe65b5eae70108ca57ff15617d379e8d6041e0&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera_dev_links.txt&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:36:19--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/a10aada0-a139-4ac9-8e2e-2ba3e7b9c13b?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043619Z&X-Amz-Expires=300&X-Amz-Signature=15c041341623e2d937ea3d8b9dbe65b5eae70108ca57ff15617d379e8d6041e0&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera_dev_links.txt&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.109.133, 185.199.110.133, 185.199.111.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.109.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 1510 (1.5K) [application/octet-stream]
Saving to: ‘libcamera_dev_links.txt’

libcamera_dev_links 100%[===================>]   1.47K  --.-KB/s    in 0.001s

2022-02-28 17:36:19 (1024 KB/s) - ‘libcamera_dev_links.txt’ saved [1510/1510]

--2022-02-28 17:36:19--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/libcamera-v0.0.5/libcamera-dev-0.0.5-bullseye.deb
Resolving github.com (github.com)... 52.64.108.95
Connecting to github.com (github.com)|52.64.108.95|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/4c43562d-2460-4747-be12-80688e89f4ee?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043620Z&X-Amz-Expires=300&X-Amz-Signature=4011a6903d0299e10da6a913bd1248fc6aba68b73e1d0a4b3e70a4730e701903&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera-dev-0.0.5-bullseye.deb&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:36:20--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/4c43562d-2460-4747-be12-80688e89f4ee?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043620Z&X-Amz-Expires=300&X-Amz-Signature=4011a6903d0299e10da6a913bd1248fc6aba68b73e1d0a4b3e70a4730e701903&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera-dev-0.0.5-bullseye.deb&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.110.133, 185.199.111.133, 185.199.108.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.110.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 665988 (650K) [application/octet-stream]
Saving to: ‘libcamera-dev-0.0.5-bullseye.deb’

libcamera-dev-0.0.5 100%[===================>] 650.38K  1.37MB/s    in 0.5s

2022-02-28 17:36:21 (1.37 MB/s) - ‘libcamera-dev-0.0.5-bullseye.deb’ saved [665988/665988]

remove libcamera0

Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
The following packages were automatically installed and are no longer required:
  libboost-program-options1.74.0 libfuse2
Use 'sudo apt autoremove' to remove them.
The following packages will be REMOVED:
  libcamera-apps libcamera-tools libcamera0
0 upgraded, 0 newly installed, 3 to remove and 32 not upgraded.
After this operation, 3,614 kB disk space will be freed.
(Reading database ... 174107 files and directories currently installed.)
Removing libcamera-apps (0~git20220105+b9a6923-1) ...
Removing libcamera-tools (0~git20220106+44d59841-2) ...
Removing libcamera0:armhf (0~git20220106+44d59841-2) ...
Processing triggers for libc-bin (2.31-13+rpt2+rpi1+deb11u2) ...
Hit:1 http://archive.raspberrypi.org/debian bullseye InRelease
Hit:2 http://raspbian.raspberrypi.org/raspbian bullseye InRelease
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
32 packages can be upgraded. Run 'apt list --upgradable' to see them.
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
Note, selecting 'libcamera-dev' instead of './libcamera-dev-0.0.5-bullseye.deb'
The following packages were automatically installed and are no longer required:
  libboost-program-options1.74.0 libfuse2
Use 'sudo apt autoremove' to remove them.
The following NEW packages will be installed:
  libcamera-dev
0 upgraded, 1 newly installed, 0 to remove and 32 not upgraded.
Need to get 0 B/666 kB of archives.
After this operation, 0 B of additional disk space will be used.
Get:1 /home/pi/libcamera-dev-0.0.5-bullseye.deb libcamera-dev armhf 0.0.5 [666 kB]
Selecting previously unselected package libcamera-dev.
(Reading database ... 174055 files and directories currently installed.)
Preparing to unpack .../libcamera-dev-0.0.5-bullseye.deb ...
Unpacking libcamera-dev (0.0.5) ...
Setting up libcamera-dev (0.0.5) ...
[email protected]:~ $ ./install_pivariety_pkgs.sh -p libcamera_apps
=================================================
Hardware Revision: 902120
Kernel Version: 5.10.92-v7+
OS Codename: bullseye
ARCH: armv7l
=================================================

--2022-02-28 17:38:52--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/install_script/libcamera_apps_links.txt
Resolving github.com (github.com)... 52.64.108.95
Connecting to github.com (github.com)|52.64.108.95|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/e518aa56-d869-4bdd-ba90-d32b61f44d65?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043853Z&X-Amz-Expires=300&X-Amz-Signature=b0be5c7f6bf0b065510a4d66bafd03d72e8d0e0200fd688d9f4f8715ee0fbaf8&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera_apps_links.txt&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:38:53--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/e518aa56-d869-4bdd-ba90-d32b61f44d65?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043853Z&X-Amz-Expires=300&X-Amz-Signature=b0be5c7f6bf0b065510a4d66bafd03d72e8d0e0200fd688d9f4f8715ee0fbaf8&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera_apps_links.txt&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.109.133, 185.199.110.133, 185.199.111.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.109.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 1645 (1.6K) [application/octet-stream]
Saving to: ‘libcamera_apps_links.txt’

libcamera_apps_link 100%[===================>]   1.61K  --.-KB/s    in 0.001s

2022-02-28 17:38:54 (2.32 MB/s) - ‘libcamera_apps_links.txt’ saved [1645/1645]

--2022-02-28 17:38:54--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/libcamera-apps-v0.0.5/libcamera-apps-0.0.5-bullseye.deb
Resolving github.com (github.com)... 52.64.108.95
Connecting to github.com (github.com)|52.64.108.95|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/8e796dd8-120a-44ee-a57f-0afc0a8964ec?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043855Z&X-Amz-Expires=300&X-Amz-Signature=51187f8f0dc3ee14e83df24f56c09588f52ac1fece42a17d72ac2720cf113ed3&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera-apps-0.0.5-bullseye.deb&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:38:55--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/8e796dd8-120a-44ee-a57f-0afc0a8964ec?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T043855Z&X-Amz-Expires=300&X-Amz-Signature=51187f8f0dc3ee14e83df24f56c09588f52ac1fece42a17d72ac2720cf113ed3&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dlibcamera-apps-0.0.5-bullseye.deb&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.110.133, 185.199.111.133, 185.199.108.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.110.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 298588 (292K) [application/octet-stream]
Saving to: ‘libcamera-apps-0.0.5-bullseye.deb’

libcamera-apps-0.0. 100%[===================>] 291.59K   961KB/s    in 0.3s

2022-02-28 17:38:56 (961 KB/s) - ‘libcamera-apps-0.0.5-bullseye.deb’ saved [298588/298588]

Hit:1 http://raspbian.raspberrypi.org/raspbian bullseye InRelease
Hit:2 http://archive.raspberrypi.org/debian bullseye InRelease
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
32 packages can be upgraded. Run 'apt list --upgradable' to see them.
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
Note, selecting 'libcamera-apps' instead of './libcamera-apps-0.0.5-bullseye.deb'
The following package was automatically installed and is no longer required:
  libfuse2
Use 'sudo apt autoremove' to remove it.
The following NEW packages will be installed:
  libcamera-apps
0 upgraded, 1 newly installed, 0 to remove and 32 not upgraded.
Need to get 0 B/299 kB of archives.
After this operation, 0 B of additional disk space will be used.
Get:1 /home/pi/libcamera-apps-0.0.5-bullseye.deb libcamera-apps armhf 0.0.5 [299 kB]
Selecting previously unselected package libcamera-apps.
(Reading database ... 174135 files and directories currently installed.)
Preparing to unpack .../libcamera-apps-0.0.5-bullseye.deb ...
Unpacking libcamera-apps (0.0.5) ...
Setting up libcamera-apps (0.0.5) ...
[email protected]:~ $ ./install_pivariety_pkgs.sh -p imx519_kernel_driver
=================================================
Hardware Revision: 902120
Kernel Version: 5.10.92-v7+
OS Codename: bullseye
ARCH: armv7l
=================================================

--2022-02-28 17:40:03--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/install_script/imx519_kernel_driver_links.txt
Resolving github.com (github.com)... 13.236.229.21
Connecting to github.com (github.com)|13.236.229.21|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/ac6f361a-5478-488c-9831-a842488255a8?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T044004Z&X-Amz-Expires=300&X-Amz-Signature=70ab3983b1a531932236273a1e0a8ccb62ced1567eb63383efae707ae80c46a5&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dimx519_kernel_driver_links.txt&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:40:04--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/ac6f361a-5478-488c-9831-a842488255a8?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T044004Z&X-Amz-Expires=300&X-Amz-Signature=70ab3983b1a531932236273a1e0a8ccb62ced1567eb63383efae707ae80c46a5&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dimx519_kernel_driver_links.txt&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.111.133, 185.199.108.133, 185.199.109.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.111.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 3986 (3.9K) [application/octet-stream]
Saving to: ‘imx519_kernel_driver_links.txt’

imx519_kernel_drive 100%[===================>]   3.89K  --.-KB/s    in 0.002s

2022-02-28 17:40:05 (1.78 MB/s) - ‘imx519_kernel_driver_links.txt’ saved [3986/3986]

--2022-02-28 17:40:05--  https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver/releases/download/Arducam_pivariety_v4l2_v1.0/imx519_v4l2_5.10.92_later.tar.gz
Resolving github.com (github.com)... 13.236.229.21
Connecting to github.com (github.com)|13.236.229.21|:443... connected.
HTTP request sent, awaiting response... 302 Found
Location: https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/4324552c-cf75-43d3-a50c-ee1db96ccc79?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T044006Z&X-Amz-Expires=300&X-Amz-Signature=269a904792f62ba8d953cd898d6360d8787436956a1e440f11da5b075d589947&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dimx519_v4l2_5.10.92_later.tar.gz&response-content-type=application%2Foctet-stream [following]
--2022-02-28 17:40:06--  https://objects.githubusercontent.com/github-production-release-asset-2e65be/353945933/4324552c-cf75-43d3-a50c-ee1db96ccc79?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAIWNJYAX4CSVEH53A%2F20220228%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20220228T044006Z&X-Amz-Expires=300&X-Amz-Signature=269a904792f62ba8d953cd898d6360d8787436956a1e440f11da5b075d589947&X-Amz-SignedHeaders=host&actor_id=0&key_id=0&repo_id=353945933&response-content-disposition=attachment%3B%20filename%3Dimx519_v4l2_5.10.92_later.tar.gz&response-content-type=application%2Foctet-stream
Resolving objects.githubusercontent.com (objects.githubusercontent.com)... 185.199.110.133, 185.199.111.133, 185.199.108.133, ...
Connecting to objects.githubusercontent.com (objects.githubusercontent.com)|185.199.110.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 56722 (55K) [application/octet-stream]
Saving to: ‘imx519_v4l2_5.10.92_later.tar.gz’

imx519_v4l2_5.10.92 100%[===================>]  55.39K   120KB/s    in 0.5s

2022-02-28 17:40:07 (120 KB/s) - ‘imx519_v4l2_5.10.92_later.tar.gz’ saved [56722/56722]

is kernel driver
Release/
Release/uninstall_driver.sh
Release/install_driver.sh
Release/arducam_camera_selector.sh
Release/bin/
Release/bin/5.10.92-v8+/
Release/bin/5.10.92-v8+/imx519.dtbo
Release/bin/5.10.92-v8+/ak7375.ko
Release/bin/5.10.92-v8+/imx519.ko
Release/bin/5.10.92+/
Release/bin/5.10.92+/imx519.dtbo
Release/bin/5.10.92+/ak7375.ko
Release/bin/5.10.92+/imx519.ko
Release/bin/5.10.92-v7l+/
Release/bin/5.10.92-v7l+/imx519.dtbo
Release/bin/5.10.92-v7l+/ak7375.ko
Release/bin/5.10.92-v7l+/imx519.ko
Release/bin/5.10.92-v7+/
Release/bin/5.10.92-v7+/imx519.dtbo
Release/bin/5.10.92-v7+/ak7375.ko
Release/bin/5.10.92-v7+/imx519.ko
Installing IMX519 and AK7375...
--------------------------------------
reboot now?(y/n):
n
cancel
[email protected]:~ $ git clone https://github.com/ArduCAM/Arducam-Pivariety-V4L2-Driver.git
Cloning into 'Arducam-Pivariety-V4L2-Driver'...
remote: Enumerating objects: 153, done.
remote: Counting objects: 100% (153/153), done.
remote: Compressing objects: 100% (115/115), done.
remote: Total 153 (delta 63), reused 118 (delta 34), pack-reused 0
Receiving objects: 100% (153/153), 105.64 KiB | 480.00 KiB/s, done.
Resolving deltas: 100% (63/63), done.
[email protected]:~ $

Thanks for your information,
It looks like the installation process is working fine,
Can you provide me with dmesg logs and pictures of the hardware connection?

If you have a stand alone version maybe you can try it first.
Since the quad camera kit has more cables, it is easier to have connection problems.

Wow! a lot of info in here, I see there is an error in the imx519 chip detection near the end of the output:

[email protected]:~ $ dmesg
[    0.000000] Booting Linux on physical CPU 0x0
[    0.000000] Linux version 5.10.92-v7+ ([email protected]) (arm-linux-gnueabihf-gcc-8 (Ubuntu/Linaro 8.4.0-3ubuntu1) 8.4.0, GNU ld (GNU Binutils for Ubuntu) 2.34) #1514 SMP Mon Jan 17 17:36:39 GMT 2022
[    0.000000] CPU: ARMv7 Processor [410fd034] revision 4 (ARMv7), cr=10c5383d
[    0.000000] CPU: div instructions available: patching division code
[    0.000000] CPU: PIPT / VIPT nonaliasing data cache, VIPT aliasing instruction cache
[    0.000000] OF: fdt: Machine model: Raspberry Pi Zero 2 W Rev 1.0
[    0.000000] random: fast init done
[    0.000000] Memory policy: Data cache writealloc
[    0.000000] Reserved memory: created CMA memory pool at 0x0bc00000, size 256 MiB
[    0.000000] OF: reserved mem: initialized node linux,cma, compatible id shared-dma-pool
[    0.000000] Zone ranges:
[    0.000000]   DMA      [mem 0x0000000000000000-0x000000001bffffff]
[    0.000000]   Normal   empty
[    0.000000] Movable zone start for each node
[    0.000000] Early memory node ranges
[    0.000000]   node   0: [mem 0x0000000000000000-0x000000001bffffff]
[    0.000000] Initmem setup node 0 [mem 0x0000000000000000-0x000000001bffffff]
[    0.000000] On node 0 totalpages: 114688
[    0.000000]   DMA zone: 1008 pages used for memmap
[    0.000000]   DMA zone: 0 pages reserved
[    0.000000]   DMA zone: 114688 pages, LIFO batch:31
[    0.000000] percpu: Embedded 20 pages/cpu s50828 r8192 d22900 u81920
[    0.000000] pcpu-alloc: s50828 r8192 d22900 u81920 alloc=20*4096
[    0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3
[    0.000000] Built 1 zonelists, mobility grouping on.  Total pages: 113680
[    0.000000] Kernel command line: coherent_pool=1M 8250.nr_uarts=0 snd_bcm2835.enable_compat_alsa=0 snd_bcm2835.enable_hdmi=1 video=HDMI-A-1:[email protected] smsc95xx.macaddr=B8:27:EB:AD:FB:47 vc_mem.mem_base=0x1ec00000 vc_mem.mem_size=0x20000000  console=ttyS0,115200 console=tty1 root=PARTUUID=825d44bc-02 rootfstype=ext4 fsck.repair=yes rootwait quiet splash plymouth.ignore-serial-consoles
[    0.000000] Dentry cache hash table entries: 65536 (order: 6, 262144 bytes, linear)
[    0.000000] Inode-cache hash table entries: 32768 (order: 5, 131072 bytes, linear)
[    0.000000] mem auto-init: stack:off, heap alloc:off, heap free:off
[    0.000000] Memory: 174692K/458752K available (10240K kernel code, 1312K rwdata, 2952K rodata, 1024K init, 862K bss, 21916K reserved, 262144K cma-reserved)
[    0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[    0.000000] ftrace: allocating 32087 entries in 95 pages
[    0.000000] ftrace: allocated 95 pages with 6 groups
[    0.000000] rcu: Hierarchical RCU implementation.
[    0.000000] 	Rude variant of Tasks RCU enabled.
[    0.000000] 	Tracing variant of Tasks RCU enabled.
[    0.000000] rcu: RCU calculated value of scheduler-enlistment delay is 10 jiffies.
[    0.000000] NR_IRQS: 16, nr_irqs: 16, preallocated irqs: 16
[    0.000000] random: get_random_bytes called from start_kernel+0x3ac/0x580 with crng_init=1
[    0.000000] arch_timer: cp15 timer(s) running at 19.20MHz (phys).
[    0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x46d987e47, max_idle_ns: 440795202767 ns
[    0.000007] sched_clock: 56 bits at 19MHz, resolution 52ns, wraps every 4398046511078ns
[    0.000021] Switching to timer-based delay loop, resolution 52ns
[    0.000318] Console: colour dummy device 80x30
[    0.000390] printk: console [tty1] enabled
[    0.000441] Calibrating delay loop (skipped), value calculated using timer frequency.. 38.40 BogoMIPS (lpj=192000)
[    0.000470] pid_max: default: 32768 minimum: 301
[    0.000660] LSM: Security Framework initializing
[    0.000899] Mount-cache hash table entries: 1024 (order: 0, 4096 bytes, linear)
[    0.000920] Mountpoint-cache hash table entries: 1024 (order: 0, 4096 bytes, linear)
[    0.002370] cgroup: Disabling memory control group subsystem
[    0.002652] CPU: Testing write buffer coherency: ok
[    0.003149] CPU0: thread -1, cpu 0, socket 0, mpidr 80000000
[    0.004364] Setting up static identity map for 0x100000 - 0x10003c
[    0.004550] rcu: Hierarchical SRCU implementation.
[    0.005469] smp: Bringing up secondary CPUs ...
[    0.006650] CPU1: thread -1, cpu 1, socket 0, mpidr 80000001
[    0.007948] CPU2: thread -1, cpu 2, socket 0, mpidr 80000002
[    0.009138] CPU3: thread -1, cpu 3, socket 0, mpidr 80000003
[    0.009294] smp: Brought up 1 node, 4 CPUs
[    0.009317] SMP: Total of 4 processors activated (153.60 BogoMIPS).
[    0.009329] CPU: All CPU(s) started in HYP mode.
[    0.009340] CPU: Virtualization extensions available.
[    0.010283] devtmpfs: initialized
[    0.028654] VFP support v0.3: implementor 41 architecture 3 part 40 variant 3 rev 4
[    0.028899] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
[    0.028929] futex hash table entries: 1024 (order: 4, 65536 bytes, linear)
[    0.039931] pinctrl core: initialized pinctrl subsystem
[    0.041287] NET: Registered protocol family 16
[    0.045835] DMA: preallocated 1024 KiB pool for atomic coherent allocations
[    0.051726] audit: initializing netlink subsys (disabled)
[    0.052039] audit: type=2000 audit(0.050:1): state=initialized audit_enabled=0 res=1
[    0.052650] thermal_sys: Registered thermal governor 'step_wise'
[    0.053814] hw-breakpoint: found 5 (+1 reserved) breakpoint and 4 watchpoint registers.
[    0.053830] hw-breakpoint: maximum watchpoint size is 8 bytes.
[    0.054169] Serial: AMBA PL011 UART driver
[    0.081287] bcm2835-mbox 3f00b880.mailbox: mailbox enabled
[    0.100194] raspberrypi-firmware soc:firmware: Attached to firmware from 2022-01-20T13:58:22, variant start
[    0.110202] raspberrypi-firmware soc:firmware: Firmware hash is bd88f66f8952d34e4e0613a85c7a6d3da49e13e2
[    0.154757] Kprobes globally optimized
[    0.160040] bcm2835-dma 3f007000.dma: DMA legacy API manager, dmachans=0x1
[    0.162508] SCSI subsystem initialized
[    0.162782] usbcore: registered new interface driver usbfs
[    0.162850] usbcore: registered new interface driver hub
[    0.162926] usbcore: registered new device driver usb
[    0.165085] clocksource: Switched to clocksource arch_sys_counter
[    1.886894] VFS: Disk quotas dquot_6.6.0
[    1.887017] VFS: Dquot-cache hash table entries: 1024 (order 0, 4096 bytes)
[    1.887237] FS-Cache: Loaded
[    1.887508] CacheFiles: Loaded
[    1.888595] simple-framebuffer 1e402000.framebuffer: framebuffer at 0x1e402000, 0x7f8000 bytes, mapped to 0x(ptrval)
[    1.888615] simple-framebuffer 1e402000.framebuffer: format=a8r8g8b8, mode=1920x1080x32, linelength=7680
[    1.889225] Console: switching to colour frame buffer device 240x67
[    1.924212] simple-framebuffer 1e402000.framebuffer: fb0: simplefb registered!
[    1.934144] NET: Registered protocol family 2
[    1.934381] IP idents hash table entries: 8192 (order: 4, 65536 bytes, linear)
[    1.936199] tcp_listen_portaddr_hash hash table entries: 512 (order: 0, 6144 bytes, linear)
[    1.936265] TCP established hash table entries: 4096 (order: 2, 16384 bytes, linear)
[    1.936350] TCP bind hash table entries: 4096 (order: 3, 32768 bytes, linear)
[    1.936454] TCP: Hash tables configured (established 4096 bind 4096)
[    1.936628] UDP hash table entries: 256 (order: 1, 8192 bytes, linear)
[    1.936671] UDP-Lite hash table entries: 256 (order: 1, 8192 bytes, linear)
[    1.936941] NET: Registered protocol family 1
[    1.937800] RPC: Registered named UNIX socket transport module.
[    1.937814] RPC: Registered udp transport module.
[    1.937826] RPC: Registered tcp transport module.
[    1.937839] RPC: Registered tcp NFSv4.1 backchannel transport module.
[    1.939848] hw perfevents: enabled with armv7_cortex_a7 PMU driver, 7 counters available
[    1.943915] Initialise system trusted keyrings
[    1.944203] workingset: timestamp_bits=14 max_order=17 bucket_order=3
[    1.953962] zbud: loaded
[    1.956215] FS-Cache: Netfs 'nfs' registered for caching
[    1.957121] NFS: Registering the id_resolver key type
[    1.957178] Key type id_resolver registered
[    1.957191] Key type id_legacy registered
[    1.957367] nfs4filelayout_init: NFSv4 File Layout Driver Registering...
[    1.957384] nfs4flexfilelayout_init: NFSv4 Flexfile Layout Driver Registering...
[    1.958609] Key type asymmetric registered
[    1.958624] Asymmetric key parser 'x509' registered
[    1.958682] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 249)
[    1.958699] io scheduler mq-deadline registered
[    1.958712] io scheduler kyber registered
[    1.968616] bcm2835-rng 3f104000.rng: hwrng registered
[    1.969221] vc-mem: phys_addr:0x00000000 mem_base=0x1ec00000 mem_size:0x20000000(512 MiB)
[    1.970506] gpiomem-bcm2835 3f200000.gpiomem: Initialised: Registers at 0x3f200000
[    1.982854] brd: module loaded
[    1.995590] loop: module loaded
[    1.997526] Loading iSCSI transport class v2.0-870.
[    1.999159] libphy: Fixed MDIO Bus: probed
[    1.999467] usbcore: registered new interface driver lan78xx
[    1.999567] usbcore: registered new interface driver smsc95xx
[    1.999593] dwc_otg: version 3.00a 10-AUG-2012 (platform bus)
[    2.727883] Core Release: 2.80a
[    2.727902] Setting default values for core params
[    2.727935] Finished setting default values for core params
[    2.928291] Using Buffer DMA mode
[    2.928305] Periodic Transfer Interrupt Enhancement - disabled
[    2.928316] Multiprocessor Interrupt Enhancement - disabled
[    2.928332] OTG VER PARAM: 0, OTG VER FLAG: 0
[    2.928349] Dedicated Tx FIFOs mode

[    2.929397] WARN::dwc_otg_hcd_init:1074: FIQ DMA bounce buffers: virt = 8bd04000 dma = 0xcbd04000 len=9024
[    2.929432] FIQ FSM acceleration enabled for :
               Non-periodic Split Transactions
               Periodic Split Transactions
               High-Speed Isochronous Endpoints
               Interrupt/Control Split Transaction hack enabled
[    2.929447] dwc_otg: Microframe scheduler enabled

[    2.929521] WARN::hcd_init_fiq:457: FIQ on core 1

[    2.929536] WARN::hcd_init_fiq:458: FIQ ASM at 807cc05c length 36

[    2.929555] WARN::hcd_init_fiq:497: MPHI regs_base at 9c810000
[    2.929580] dwc_otg 3f980000.usb: DWC OTG Controller
[    2.929620] dwc_otg 3f980000.usb: new USB bus registered, assigned bus number 1
[    2.929672] dwc_otg 3f980000.usb: irq 89, io mem 0x00000000
[    2.929729] Init: Port Power? op_state=1
[    2.929741] Init: Power Port (0)
[    2.930105] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 5.10
[    2.930122] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[    2.930138] usb usb1: Product: DWC OTG Controller
[    2.930153] usb usb1: Manufacturer: Linux 5.10.92-v7+ dwc_otg_hcd
[    2.930168] usb usb1: SerialNumber: 3f980000.usb
[    2.930959] hub 1-0:1.0: USB hub found
[    2.931025] hub 1-0:1.0: 1 port detected
[    2.932433] dwc_otg: FIQ enabled
[    2.932446] dwc_otg: NAK holdoff enabled
[    2.932459] dwc_otg: FIQ split-transaction FSM enabled
[    2.932479] Module dwc_common_port init
[    2.932828] usbcore: registered new interface driver usb-storage
[    2.933060] mousedev: PS/2 mouse device common for all mice
[    2.934468] bcm2835-wdt bcm2835-wdt: Broadcom BCM2835 watchdog timer
[    2.937237] sdhci: Secure Digital Host Controller Interface driver
[    2.937251] sdhci: Copyright(c) Pierre Ossman
[    2.937974] mmc-bcm2835 3f300000.mmcnr: could not get clk, deferring probe
[    2.938699] sdhost-bcm2835 3f202000.mmc: could not get clk, deferring probe
[    2.938982] sdhci-pltfm: SDHCI platform and OF driver helper
[    2.940041] ledtrig-cpu: registered to indicate activity on CPUs
[    2.940368] hid: raw HID events driver (C) Jiri Kosina
[    2.940538] usbcore: registered new interface driver usbhid
[    2.940550] usbhid: USB HID core driver
[    2.946388] Initializing XFRM netlink socket
[    2.946438] NET: Registered protocol family 17
[    2.946608] Key type dns_resolver registered
[    2.947374] Registering SWP/SWPB emulation handler
[    2.947546] registered taskstats version 1
[    2.947579] Loading compiled-in X.509 certificates
[    2.948453] Key type ._fscrypt registered
[    2.948469] Key type .fscrypt registered
[    2.948482] Key type fscrypt-provisioning registered
[    2.960889] uart-pl011 3f201000.serial: cts_event_workaround enabled
[    2.961018] 3f201000.serial: ttyAMA0 at MMIO 0x3f201000 (irq = 114, base_baud = 0) is a PL011 rev2
[    2.963469] bcm2835-power bcm2835-power: Broadcom BCM2835 power domains driver
[    2.965331] mmc-bcm2835 3f300000.mmcnr: mmc_debug:0 mmc_debug2:0
[    2.965349] mmc-bcm2835 3f300000.mmcnr: DMA channel allocated
[    2.992354] sdhost: log_buf @ (ptrval) (cbd03000)
[    3.030447] mmc1: queuing unknown CIS tuple 0x80 (2 bytes)
[    3.032150] mmc1: queuing unknown CIS tuple 0x80 (3 bytes)
[    3.033831] mmc1: queuing unknown CIS tuple 0x80 (3 bytes)
[    3.036835] mmc1: queuing unknown CIS tuple 0x80 (7 bytes)
[    3.038512] mmc1: queuing unknown CIS tuple 0x80 (3 bytes)
[    3.041037] mmc0: sdhost-bcm2835 loaded - DMA enabled (>1)
[    3.044189] of_cfs_init
[    3.044495] of_cfs_init: OK
[    3.046018] Waiting for root device PARTUUID=825d44bc-02...
[    3.062155] Indeed it is in host mode hprt0 = 00021501
[    3.188787] mmc0: host does not support reading read-only switch, assuming write-enable
[    3.192539] mmc0: new high speed SDHC card at address aaaa
[    3.193551] mmcblk0: mmc0:aaaa SC16G 14.8 GiB
[    3.197142]  mmcblk0: p1 p2
[    3.221956] mmc1: new high speed SDIO card at address 0001
[    3.240155] EXT4-fs (mmcblk0p2): mounted filesystem with ordered data mode. Opts: (null)
[    3.240257] VFS: Mounted root (ext4 filesystem) readonly on device 179:2.
[    3.248527] devtmpfs: mounted
[    3.256361] Freeing unused kernel memory: 1024K
[    3.265151] usb 1-1: new high-speed USB device number 2 using dwc_otg
[    3.265627] Run /sbin/init as init process
[    3.265639]   with arguments:
[    3.265650]     /sbin/init
[    3.265662]     splash
[    3.265673]   with environment:
[    3.265686]     HOME=/
[    3.265697]     TERM=linux
[    3.266072] Indeed it is in host mode hprt0 = 00001101
[    3.518052] usb 1-1: New USB device found, idVendor=05e3, idProduct=0610, bcdDevice=92.26
[    3.518079] usb 1-1: New USB device strings: Mfr=1, Product=2, SerialNumber=0
[    3.518097] usb 1-1: Product: USB2.0 Hub
[    3.518112] usb 1-1: Manufacturer: GenesysLogic
[    3.519068] hub 1-1:1.0: USB hub found
[    3.519380] hub 1-1:1.0: 4 ports detected
[    3.810980] systemd[1]: System time before build time, advancing clock.
[    3.855187] usb 1-1.3: new full-speed USB device number 3 using dwc_otg
[    3.967408] NET: Registered protocol family 10
[    3.969015] Segment Routing with IPv6
[    3.993976] usb 1-1.3: New USB device found, idVendor=046d, idProduct=c52f, bcdDevice=30.00
[    3.994004] usb 1-1.3: New USB device strings: Mfr=1, Product=2, SerialNumber=0
[    3.994022] usb 1-1.3: Product: USB Receiver
[    3.994037] usb 1-1.3: Manufacturer: Logitech
[    4.004106] input: Logitech USB Receiver as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.3/1-1.3:1.0/0003:046D:C52F.0001/input/input0
[    4.004750] hid-generic 0003:046D:C52F.0001: input,hidraw0: USB HID v1.11 Mouse [Logitech USB Receiver] on usb-3f980000.usb-1.3/input0
[    4.011735] input: Logitech USB Receiver Consumer Control as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.3/1-1.3:1.1/0003:046D:C52F.0002/input/input1
[    4.065428] systemd[1]: systemd 247.3-6+rpi1 running in system mode. (+PAM +AUDIT +SELINUX +IMA +APPARMOR +SMACK +SYSVINIT +UTMP +LIBCRYPTSETUP +GCRYPT +GNUTLS +ACL +XZ +LZ4 +ZSTD +SECCOMP +BLKID +ELFUTILS +KMOD +IDN2 -IDN +PCRE2 default-hierarchy=unified)
[    4.066633] systemd[1]: Detected architecture arm.
[    4.072294] systemd[1]: Set hostname to <raspberrypi>.
[    4.075963] hid-generic 0003:046D:C52F.0002: input,hiddev96,hidraw1: USB HID v1.11 Device [Logitech USB Receiver] on usb-3f980000.usb-1.3/input1
[    4.185248] usb 1-1.4: new high-speed USB device number 4 using dwc_otg
[    4.331607] usb 1-1.4: New USB device found, idVendor=413c, idProduct=1010, bcdDevice=32.98
[    4.331636] usb 1-1.4: New USB device strings: Mfr=0, Product=11, SerialNumber=0
[    4.331654] usb 1-1.4: Product: USB 2.0 Hub [MTT]
[    4.332778] hub 1-1.4:1.0: USB hub found
[    4.334470] hub 1-1.4:1.0: 4 ports detected
[    4.655217] usb 1-1.4.4: new low-speed USB device number 5 using dwc_otg
[    4.845502] usb 1-1.4.4: New USB device found, idVendor=413c, idProduct=2110, bcdDevice= 0.06
[    4.845531] usb 1-1.4.4: New USB device strings: Mfr=1, Product=2, SerialNumber=0
[    4.845548] usb 1-1.4.4: Product: Dell Wired Multimedia Keyboard
[    4.845563] usb 1-1.4.4: Manufacturer: Dell
[    4.873472] input: Dell Dell Wired Multimedia Keyboard as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4.4/1-1.4.4:1.0/0003:413C:2110.0003/input/input4
[    4.936026] hid-generic 0003:413C:2110.0003: input,hidraw2: USB HID v1.10 Keyboard [Dell Dell Wired Multimedia Keyboard] on usb-3f980000.usb-1.4.4/input0
[    4.981187] input: Dell Dell Wired Multimedia Keyboard Mouse as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4.4/1-1.4.4:1.1/0003:413C:2110.0004/input/input5
[    4.981794] input: Dell Dell Wired Multimedia Keyboard System Control as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4.4/1-1.4.4:1.1/0003:413C:2110.0004/input/input6
[    5.045752] input: Dell Dell Wired Multimedia Keyboard Consumer Control as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4.4/1-1.4.4:1.1/0003:413C:2110.0004/input/input7
[    5.046264] hid-generic 0003:413C:2110.0004: input,hiddev97,hidraw3: USB HID v1.10 Mouse [Dell Dell Wired Multimedia Keyboard] on usb-3f980000.usb-1.4.4/input1
[    5.076080] systemd[1]: /lib/systemd/system/plymouth-start.service:16: Unit configured to use KillMode=none. This is unsafe, as it disables systemd's process lifecycle management for the service. Please update your service to use a safer KillMode=, such as 'mixed' or 'control-group'. Support for KillMode=none is deprecated and will eventually be removed.


… the remainder.

The error is at 11.18 and 11.19

[    5.351876] systemd[1]: Queued start job for default target Graphical Interface.
[    5.354796] random: systemd: uninitialized urandom read (16 bytes read)
[    5.358475] systemd[1]: Created slice system-getty.slice.
[    5.358989] random: systemd: uninitialized urandom read (16 bytes read)
[    5.360362] systemd[1]: Created slice system-modprobe.slice.
[    5.360602] random: systemd: uninitialized urandom read (16 bytes read)
[    5.361805] systemd[1]: Created slice system-systemd\x2dfsck.slice.
[    5.362876] systemd[1]: Created slice User and Session Slice.
[    5.363599] systemd[1]: Started Forward Password Requests to Wall Directory Watch.
[    5.365270] systemd[1]: Set up automount Arbitrary Executable File Formats File System Automount Point.
[    5.366550] systemd[1]: Reached target Slices.
[    5.366941] systemd[1]: Reached target Swap.
[    5.368583] systemd[1]: Listening on Syslog Socket.
[    5.369523] systemd[1]: Listening on fsck to fsckd communication Socket.
[    5.370046] systemd[1]: Listening on initctl Compatibility Named Pipe.
[    5.371660] systemd[1]: Listening on Journal Audit Socket.
[    5.372604] systemd[1]: Listening on Journal Socket (/dev/log).
[    5.373747] systemd[1]: Listening on Journal Socket.
[    5.384450] systemd[1]: Listening on udev Control Socket.
[    5.385654] systemd[1]: Listening on udev Kernel Socket.
[    5.387146] systemd[1]: Condition check resulted in Huge Pages File System being skipped.
[    5.392379] systemd[1]: Mounting POSIX Message Queue File System...
[    5.399157] systemd[1]: Mounting RPC Pipe File System...
[    5.406719] systemd[1]: Mounting Kernel Debug File System...
[    5.414397] systemd[1]: Mounting Kernel Trace File System...
[    5.415805] systemd[1]: Condition check resulted in Kernel Module supporting RPCSEC_GSS being skipped.
[    5.428648] systemd[1]: Starting Restore / save the current clock...
[    5.440811] systemd[1]: Starting Set the console keyboard layout...
[    5.449314] systemd[1]: Starting Create list of static device nodes for the current kernel...
[    5.457408] systemd[1]: Starting Load Kernel Module configfs...
[    5.465801] systemd[1]: Starting Load Kernel Module drm...
[    5.475290] systemd[1]: Starting Load Kernel Module fuse...
[    5.484022] systemd[1]: Condition check resulted in Set Up Additional Binary Formats being skipped.
[    5.502635] systemd[1]: Starting File System Check on Root Device...
[    5.520380] systemd[1]: Starting Journal Service...
[    5.534670] systemd[1]: Starting Load Kernel Modules...
[    5.557592] systemd[1]: Starting Coldplug All udev Devices...
[    5.565464] fuse: init (API version 7.32)
[    5.587679] systemd[1]: Mounted POSIX Message Queue File System.
[    5.588557] systemd[1]: Mounted RPC Pipe File System.
[    5.589320] systemd[1]: Mounted Kernel Debug File System.
[    5.590035] systemd[1]: Mounted Kernel Trace File System.
[    5.592707] systemd[1]: Finished Create list of static device nodes for the current kernel.
[    5.595589] systemd[1]: [email protected]: Succeeded.
[    5.596944] systemd[1]: Finished Load Kernel Module configfs.
[    5.599149] systemd[1]: [email protected]: Succeeded.
[    5.600811] systemd[1]: Finished Load Kernel Module fuse.
[    5.625430] systemd[1]: Mounting FUSE Control File System...
[    5.636396] systemd[1]: Mounting Kernel Configuration File System...
[    5.658424] systemd[1]: Started File System Check Daemon to report status.
[    5.671197] i2c /dev entries driver
[    5.704188] systemd[1]: Finished Restore / save the current clock.
[    5.725424] systemd[1]: [email protected]: Succeeded.
[    5.726957] systemd[1]: Finished Load Kernel Module drm.
[    5.729574] systemd[1]: Finished Load Kernel Modules.
[    5.730765] systemd[1]: Mounted FUSE Control File System.
[    5.731515] systemd[1]: Mounted Kernel Configuration File System.
[    5.743592] systemd[1]: Starting Apply Kernel Variables...
[    5.841331] systemd[1]: Finished Apply Kernel Variables.
[    5.905921] systemd[1]: Finished File System Check on Root Device.
[    5.911935] systemd[1]: Starting Remount Root and Kernel File Systems...
[    5.978729] systemd[1]: Started Journal Service.
[    6.132565] EXT4-fs (mmcblk0p2): re-mounted. Opts: (null)
[    6.226671] systemd-journald[123]: Received client request to flush runtime journal.
[    6.258954] systemd-journald[123]: File /var/log/journal/cfd51774f0e74a22a64212417099564f/system.journal corrupted or uncleanly shut down, renaming and replacing.
[    7.995197] random: crng init done
[    7.995224] random: 7 urandom warning(s) missed due to ratelimiting
[    8.045656] vc_sm_cma: module is from the staging directory, the quality is unknown, you have been warned.
[    8.048790] bcm2835_vc_sm_cma_probe: Videocore shared memory driver
[    8.048822] [vc_sm_connected_init]: start
[    8.055048] [vc_sm_connected_init]: installed successfully
[    8.078339] mc: Linux media interface: v0.10
[    8.137200] videodev: Linux video capture interface: v2.00
[    8.164254] snd_bcm2835: module is from the staging directory, the quality is unknown, you have been warned.
[    8.166875] bcm2835_audio bcm2835_audio: there is not valid maps for state default
[    8.176019] bcm2835_mmal_vchiq: module is from the staging directory, the quality is unknown, you have been warned.
[    8.178357] bcm2835_mmal_vchiq: module is from the staging directory, the quality is unknown, you have been warned.
[    8.186262] bcm2835_isp: module is from the staging directory, the quality is unknown, you have been warned.
[    8.190511] bcm2835_v4l2: module is from the staging directory, the quality is unknown, you have been warned.
[    8.208269] bcm2835_codec: module is from the staging directory, the quality is unknown, you have been warned.
[    8.229289] bcm2835-codec bcm2835-codec: Device registered as /dev/video10
[    8.229352] bcm2835-codec bcm2835-codec: Loaded V4L2 decode
[    8.230281] bcm2835-isp bcm2835-isp: Device node output[0] registered as /dev/video13
[    8.231344] bcm2835-isp bcm2835-isp: Device node capture[0] registered as /dev/video14
[    8.232534] bcm2835-isp bcm2835-isp: Device node capture[1] registered as /dev/video15
[    8.233810] bcm2835-isp bcm2835-isp: Device node stats[2] registered as /dev/video16
[    8.233861] bcm2835-isp bcm2835-isp: Register output node 0 with media controller
[    8.233888] bcm2835-isp bcm2835-isp: Register capture node 1 with media controller
[    8.233957] bcm2835-isp bcm2835-isp: Register capture node 2 with media controller
[    8.233980] bcm2835-isp bcm2835-isp: Register capture node 3 with media controller
[    8.234986] bcm2835-codec bcm2835-codec: Device registered as /dev/video11
[    8.239685] bcm2835-codec bcm2835-codec: Loaded V4L2 encode
[    8.242494] bcm2835-isp bcm2835-isp: Device node output[0] registered as /dev/video20
[    8.243934] bcm2835-isp bcm2835-isp: Device node capture[0] registered as /dev/video21
[    8.246950] bcm2835-isp bcm2835-isp: Device node capture[1] registered as /dev/video22
[    8.247499] bcm2835-codec bcm2835-codec: Device registered as /dev/video12
[    8.247565] bcm2835-codec bcm2835-codec: Loaded V4L2 isp
[    8.249596] bcm2835-isp bcm2835-isp: Device node stats[2] registered as /dev/video23
[    8.249648] bcm2835-isp bcm2835-isp: Register output node 0 with media controller
[    8.249678] bcm2835-isp bcm2835-isp: Register capture node 1 with media controller
[    8.249699] bcm2835-isp bcm2835-isp: Register capture node 2 with media controller
[    8.249728] bcm2835-isp bcm2835-isp: Register capture node 3 with media controller
[    8.251129] bcm2835-isp bcm2835-isp: Loaded V4L2 bcm2835-isp
[    8.252102] bcm2835-codec bcm2835-codec: Device registered as /dev/video18
[    8.252168] bcm2835-codec bcm2835-codec: Loaded V4L2 image_fx
[    8.399678] i2c i2c-11: Added multiplexed i2c bus 0
[    8.401557] i2c i2c-11: Added multiplexed i2c bus 10
[    8.716686] checking generic (1e402000 7f8000) vs hw (0 ffffffff)
[    8.716716] fb0: switching to vc4drmfb from simple
[    8.717533] Console: switching to colour dummy device 80x30
[    8.730876] vc4-drm soc:gpu: bound 3f400000.hvs (ops vc4_hvs_ops [vc4])
[    8.731959] Registered IR keymap rc-cec
[    8.732220] rc rc0: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0
[    8.732562] input: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0/input8
[    9.237159] cfg80211: Loading compiled-in X.509 certificates for regulatory database
[    9.338889] logitech-djreceiver 0003:046D:C52F.0001: hidraw0: USB HID v1.11 Mouse [Logitech USB Receiver] on usb-3f980000.usb-1.3/input0
[    9.388151] cfg80211: Loaded X.509 cert 'sforshee: 00b28ddf47aef9cea7'
[    9.411094] vc4-drm soc:gpu: bound 3f400000.hvs (ops vc4_hvs_ops [vc4])
[    9.412434] Registered IR keymap rc-cec
[    9.412759] rc rc0: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0
[    9.413135] input: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0/input9
[    9.418709] cfg80211: loaded regulatory.db is malformed or signature is missing/invalid
[    9.490470] brcmfmac: F1 signature read @0x18000000=0x1541a9a6
[    9.500810] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43436s-sdio for chip BCM43430/1
[    9.502134] usbcore: registered new interface driver brcmfmac
[    9.520855] logitech-djreceiver 0003:046D:C52F.0002: hiddev96,hidraw1: USB HID v1.11 Device [Logitech USB Receiver] on usb-3f980000.usb-1.3/input1
[    9.594607] logitech-djreceiver 0003:046D:C52F.0002: device of type eQUAD step 4 DJ (0x04) connected on slot 1
[    9.612205] input: Logitech Wireless Mouse PID:4008 Mouse as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.3/1-1.3:1.1/0003:046D:C52F.0002/0003:046D:4008.0005/input/input10
[    9.627771] input: Logitech Wireless Mouse PID:4008 Consumer Control as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.3/1-1.3:1.1/0003:046D:C52F.0002/0003:046D:4008.0005/input/input11
[    9.635393] hid-generic 0003:046D:4008.0005: input,hidraw4: USB HID v1.11 Mouse [Logitech Wireless Mouse PID:4008] on usb-3f980000.usb-1.3/input1:1
[    9.637865] vc4-drm soc:gpu: bound 3f400000.hvs (ops vc4_hvs_ops [vc4])
[    9.668319] Registered IR keymap rc-cec
[    9.668864] rc rc0: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0
[    9.669455] input: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0/input15
[    9.748447] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43436s-sdio for chip BCM43430/1
[    9.748596] brcmfmac: brcmf_fw_alloc_request: using brcm/brcmfmac43436s-sdio for chip BCM43430/1
[    9.748690] brcmfmac: brcmf_c_process_clm_blob: no clm_blob available (err=-2), device may have limited channels available
[    9.749317] brcmfmac: brcmf_c_preinit_dcmds: Firmware: BCM43430/1 wl0: Feb  5 2021 12:49:07 version 7.45.96 (r745790) FWID 01-71817851 es7
[    9.793574] vc4-drm soc:gpu: bound 3f400000.hvs (ops vc4_hvs_ops [vc4])
[    9.794972] Registered IR keymap rc-cec
[    9.797016] rc rc0: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0
[    9.797339] input: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0/input16
[   10.674232] vc4-drm soc:gpu: bound 3f400000.hvs (ops vc4_hvs_ops [vc4])
[   10.680845] Registered IR keymap rc-cec
[   10.681099] rc rc0: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0
[   10.681387] input: vc4 as /devices/platform/soc/3f902000.hdmi/rc/rc0/input17
[   10.695399] vc4-drm soc:gpu: bound 3f902000.hdmi (ops vc4_hdmi_ops [vc4])
[   10.695851] vc4-drm soc:gpu: bound 3f004000.txp (ops vc4_txp_ops [vc4])
[   10.696185] vc4-drm soc:gpu: bound 3f206000.pixelvalve (ops vc4_crtc_ops [vc4])
[   10.696505] vc4-drm soc:gpu: bound 3f207000.pixelvalve (ops vc4_crtc_ops [vc4])
[   10.696799] vc4-drm soc:gpu: bound 3f807000.pixelvalve (ops vc4_crtc_ops [vc4])
[   10.697065] vc4-drm soc:gpu: bound 3fc00000.v3d (ops vc4_v3d_ops [vc4])
[   10.721800] [drm] Initialized vc4 0.0.0 20140616 for soc:gpu on minor 0
[   10.853392] Console: switching to colour frame buffer device 240x67
[   10.892465] vc4-drm soc:gpu: [drm] fb0: vc4drmfb frame buffer device
[   11.035632] ak7375: loading out-of-tree module taints kernel.
[   11.185427] imx519 10-001a: failed to read chip id 519, with error -5
[   11.191130] imx519: probe of 10-001a failed with error -5
[   11.549784] input: Logitech M185 as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.3/1-1.3:1.1/0003:046D:C52F.0002/0003:046D:4008.0005/input/input18
[   11.550627] logitech-hidpp-device 0003:046D:4008.0005: input,hidraw4: USB HID v1.11 Mouse [Logitech M185] on usb-3f980000.usb-1.3/input1:1
[   11.708788] uart-pl011 3f201000.serial: no DMA platform data
[   11.895707] Adding 102396k swap on /var/swap.  Priority:-2 extents:1 across:102396k SSFS
[   12.136863] 8021q: 802.1Q VLAN Support v1.8
[   12.813589] brcmfmac: brcmf_cfg80211_set_power_mgmt: power save enabled
[   14.450735] IPv6: ADDRCONF(NETDEV_CHANGE): wlan0: link becomes ready
[   15.976637] Bluetooth: Core ver 2.22
[   15.976751] NET: Registered protocol family 31
[   15.976760] Bluetooth: HCI device and connection manager initialized
[   15.976787] Bluetooth: HCI socket layer initialized
[   15.976802] Bluetooth: L2CAP socket layer initialized
[   15.976828] Bluetooth: SCO socket layer initialized
[   15.983571] ICMPv6: process `dhcpcd' is using deprecated sysctl (syscall) net.ipv6.neigh.wlan0.retrans_time - use net.ipv6.neigh.wlan0.retrans_time_ms instead
[   15.994015] Bluetooth: HCI UART driver ver 2.3
[   15.994034] Bluetooth: HCI UART protocol H4 registered
[   15.994136] Bluetooth: HCI UART protocol Three-wire (H5) registered
[   15.994375] Bluetooth: HCI UART protocol Broadcom registered
[   16.416704] Bluetooth: BNEP (Ethernet Emulation) ver 1.3
[   16.416720] Bluetooth: BNEP filters: protocol multicast
[   16.416740] Bluetooth: BNEP socket layer initialized
[   16.452081] NET: Registered protocol family 38
[   16.498118] cryptd: max_cpu_qlen set to 1000
[   19.275035] Bluetooth: RFCOMM TTY layer initialized
[   19.275175] Bluetooth: RFCOMM socket layer initialized
[   19.275209] Bluetooth: RFCOMM ver 1.11
[   33.115156] cam1-reg: disabling
[   33.115181] cam-dummy-reg: disabling
[  113.274714] logitech-hidpp-device 0003:046D:4008.0005: HID++ 2.0 device connected.

I’ve attached a photo of the connection (I’m not using the quad camera hat, just the individual cameras)

Yes, the driver did not read the ID of the IMX519.
The cable connection looks normal.
Another thing you need to note is that you can’t use the camera in the quad kit alone…

Hm, that’s not good news… That was our intention, we require the native resolution for some projects.

Can you please explain why, and whether there’s some way we might try to resolve this.

Do you mean why can’t the IMX519 in the quad kit be used alone?
This is because the camera module in the quad kit is different from the normal version, of course you can make it work independently by hardware modification (moving the position of a resistor).

Yes, exactly.

Perhaps you can attach a diagram explaining how to make the modification, and we can then close the thread.

quad kit version:

normal version:

In addition, it is necessary to remind that there is a risk of damage to self-modification, and we are not responsible for it.

Yes, that couldn’t be in a much more difficult spot. I’m not sure it’s going to be possible to be honest. For completeness, do you have the details of the resistor?

Thanks a lot for your support.

You don’t need to replace the resistor, just move the position.
Here is the resistor related information:

0 Ohms Jumper 0.063W, 1/16W Chip Resistor 0402 (1005 Metric) Moisture Resistant Thick Film
RC0402JR-130RL

I think we have some misunderstandings, the camera you bought is the quad kit from Kickstarter, it contains 4xIMX519, but there is no quad hat, right?
I think I misunderstood that what you bought is quad hat + 4ximx519.

Can you remove the case of the IMX519 and take a picture of the back for us to confirm the camera status?

Here is the quad hat kit I mentioned:

Yes, you’re correct.

However, for us, purchasing the quad hat kit was a convenient way to purchase 4 cameras, and get some extra hardware, for when we need it. It wasn’t clear from the documentation that the IMX519 that comes with the quad hat (which was included, thanks) would be different from the IMX519 that comes as a stand-alone unit.

If I’m not mistaken, the quad hat synchronizes the cameras, but reduces the resolution of images, before it combines them into a single file. While useful for us later, that’s not where we want to start right now, we require the full resolution from each camera.

While I feel the sales documentation could’ve been clearer, your support has been great in terms of identifying the problem. Right now I’m trying to figure out how to move forward without damaging the cameras, or waiting several months for a new production run.

Sorry, we didn’t write this on the sales description. I’ll remind our salesperson.

Correct.

I’m not sure if you have the equipment to modify the resistors, if you have the equipment, you can try it, because only one resistor needs to be modified and if you are careful enough it shouldn’t damage the camera.

Also I will forward your email to [email protected] to see if they have any other suggestions.
